| Specifications |
| Model |
LPS2830 |
| Size Channels |
0.5 μm, 5.0 μm |
| Flow Rate |
28.3L/min [1CFM] |
| Optical Sensor |
Laser Diode |
| Counting Efficiency |
GMP, ISO14644, FDA, JJF1190-2008 |
| Max Detectable Concentration for 0.5 μ |
500,000CNT/ft3 |
| Max Detectable Concentration for 5.0 μ |
500,000CNT/ft3 |
| Concentration Limit for 0.5 μ |
500,000 particles/ft3 at 10% coincidence loss
Sampling Time: 1 to 60 seconds
Output Range Setting (To be configured for each particle size)
Count: 0-10CNT, 0-100CNT, 0-1,000CNT, 0-10,000CNT
Concentration: 0-10CNT/cf, 0-100CNT/cf, 0-1,000CNT/cf, |
| Setting Parameter |
0-1,000,000CNT/cf, 0-353CNT/ m3, 0-3,530CNT/m3,
-35,300CNT/m3, 0-35,300,000CNT/m3
Alarm Setting: 0%-100%
Address Setting: 0-9600
error Output Setting: ON/OFF |
| Sampling Pump |
Inbuilt vacuum>51kPa |
| Interface & Communication |
RS485, Analog Output (4-20mA), [ 0 to 10 V for calibration] |
| Setting Software |
English |
| Operating Environment |
Temperature:10℃-40℃; Humidity:20%-90%RH; Atmosphere
Pressure:86-106Kpa
|
| Storing Environment |
14 to 122°F (-10 to 50°C), up to 98%RH with no visible
condensation |
| Outside Dimensions |
275*450*175 mm³(Wide*Deep*High) |
| Weight |
4kg |
| Max. Consumption |
40W |
| Power Supply |
DC24V |
| Laser Power |
Wave length 775 to 800 nm [1550 to 1600mV] Output 80 mW |
| Laser classification |
lass 1 EN60825-1 : 2007 [0 to 10V] |
| Peak Noise |
Less than 200 mV |
